Aluminium Round Bars

Name: Aluminium Round Bars
Brand: Shenzhen Oriental Turdo Ironwares Co., Ltd.

Aluminium round bar is frequently used in the transportation, construction and aviation industries due to its excellent strength to weight ratio.

In Otalum, we offer a wide range of aluminium round bars with a variety of alloys, sizes and finishes. Our solid aluminum round bar can also be cut to a specific size if the existing products cannot meet your requirement.

Moreover, just like the customization services Otalum provides for all the other aluminum extrusions profiles, precise cutting to length and other processing services of aluminium hollow/solid round bars are also available with the fastest lead time.

Get a Quote

Features of Aluminum Round Bars

Alloy	Standard	Surface Treatment	Further Process	Certificate
6005 T5/T6, 6060 T5/T6, 6061 T4/T6, 6063 T5/T6, 6463 T5/T6, 6082 T5/T6, etc.	GB 5237-2008, JISH, AAMA, GB, BS, En	Mill finish, Powder Coating, Anodizing, Wooden grain, Electrophoresis, PVDF Painting, Sanding blasting, Polishing, etc.	Drilling, Bending, Welding, Precise cutting, Punching, Fabrication of finished products, etc.	CE, DNV, TUV, ISO9001

Specifications of Aluminum Round Bars

Aluminum Round Bars

Φ=diameter, mm

Weight(kg/m)

Item	Φ(mm)	Weight(kg/m)
RW1913B	4.75	0.049
JED-001C	4.95	0.051
OS-SD005	6.35	0.086
ZY-236-CHB0500	6.35	0.086
CO-3P	7.94	0.135
70047KMB	9.53	0.192
ARC079	10	0.213
CO-4P	11.11	0.262
OS-SD003	12.7	0.343
RD15	15	0.487
OS-SD004	15.88	0.535
ZYW0835	16	0.543
DT030	17.48	0.648
OS-SD001	19.05	0.77
SRR20	20	0.848
SRR23	23	1.121
SRR24	24	1.22
SRR25.4	25.4	1.369
SRR28	28	1.663
TC122	31.75	2.138
SRR32	32	2.171
ZY-044-026	34	2.452
ZY-116-018	36	2.749
RD42	42	3.78
RD050	50	5.3
CO-7P	50.8	5.473
SRR57	57	6.89
ROD60	60	7.661
RD63.5	63.5	8.65
RD0065	65	8.959
SRR70	70	10.39
RD0072	72	10.99
CF-ROD80	80	13.623
SRR83	83	14.61

Aluminum Round Bar Casting Process

Smelting and casting process includes smelting, purification, impurity removal, degassing, slag removal and casting. The main process is:

(1) Composition: According to the specific alloy grades to be produced, calculate the addition amount of various alloy components, and reasonably match various raw materials.

(2) Smelting: The prepared raw materials are smelted in a smelting furnace according to the process requirements, and the slag and gas in the melt are effectively removed through degassing and slagging refining methods.

(3) Casting: Under certain casting process conditions, the aluminum liquid is cooled and cast into various specifications of round casting rods through the deep well casting system.

Aluminium Construction Profiles

Industrial Aluminum Profile

Standard Aluminium Extrusion Shapes

Professional Aluminium Extrusion Supplier

 info@otalum.com

 0086-755-29991176

 Room 3/22, COFCO Group Center, Baoan District, Shenzhen, Guangdong Province, China

Get A Free Quote

START NOW

When ordering, pls specify alloy, temper, length, quantity, surface finish, end-use and any special instructions regarding tolerance, delivery, packing and certification. It couldn’t be better if you can share with us your designed drawings. If you have any questions, pls contact us without hesitation. Thanks.
